Nitgen eNBioAccess-T5
Biometric Terminal Nitgen eNBioAccess T5 is the ideal solution for Access Control and Time & Attendance control, highly reliable and accurate, based on TCP/IP communication.
Nitgen ENBioAccess-T5
eNBioAccess-T5 is a Real time fingerprints authentication Time attendance and access control system capable of speedy authentication with LFD function (Live Finger Detection) and supports.
It offers you enterprise level of Entry and Time Attendance management with its built-in camera takes picture for every transaction with storage in server. POE LAN communication-based network infrastructure enabling integrated monitoring and systematic management of multiple terminals operated independently on a remote location. Inbuilt rely & power for electromagnetic locks.
Features
4.3″ TFT LCD, Touch Screen
– Fingerprint Image Quality Check
– Notice/Status bar
– Wallpaper with company logo
Superior Matching Engine
– 1st rank in FVC(Fingerprint Verification Competition)
Auto-on Function & Live Finger Detection
Built-in Camera
– Takes picture for every transaction with storage in server
USB Memory Slot
– Easy data transfer using USB memory stick
Function Key
– User-defined functions (F1~F4)
– Clock In/Clock Out/Absence/Return
Multifactor Authentication
– Fingerprint, RF card, Password
Multi Language support with Audio-visual indications
Built-in battery & PoE (Optional)
Centralized Biometric Access control on IP technology
Multi-processing functionality
– Normal authentication process under progress at background of terminal
Alternate devices such as enBio Access-T1, enBio Access-T2, FingerAccess2, eNCard-I, eNBio Access-T9 series and UBio-X slim, UBioX-Pro, UBio-X Pro lite and UBio Tablet5 series.
eNBioAccess-T5 user interface ver easy to use and highly customizable, upload customized wallpaper of your company logo to make it look attactive. Option to have Function key that can be used for Break-In, Break-OUT. Different level of authentication security levels, multi-factor authentication for fingerprint, password or RF card. It can be configured in centralized access control using TCP/IP technology.
Access control or time and attendance options is available or accessed using fingerprint, card or password. They can also be used in conjunction to elevate the level of security (multi-factor authentication). Multi-factor authentication ensures that you get superior grade of security against unauthorized users.
| CPU | S3C6410 (ARM11 667MHz) |
| Memory | 256MB DRAM / 256MB Flash |
| Display | 4.3″ TFT LCD / Touch Screen |
| Sensor | Optical / 500 DPI |
| 1:1 Time | < 0.2 sec. |
| 1:N Time | < 1 sec.(4,000 templates) |
| Authentication Rate | FRR ~=0.1%, FAR ~= 0.001% |
| Template Capacity | 100,000 templates (2templates/1finger) |
| Log Capacity | 500,000 logs |
| Communication | TCP/IP, Wiegand In/Out(26/34bit) |
| Lock | Deadbolt, EM Lock, Door Strike, Automatic Door |
| Environment | -20~60 ℃ / < RH 90% |
| Certificate | KC, CE, FCC |
| Size (mm) | 192 x 156 x 55 (W x H x D) |
Features :
- 4.3″ TFT LCD, Touch Screen
- Fingerprint Image Quality Check
- Notice/Status bar
- Superior Matching Engine
- 1st rank in FVC(Fingerprint Verification Competition)
- Auto-on Function & Live Finger Detection
- Built-in Camera: Takes picture for every transaction with storage in server
- USB Memory Slot: Easy data transfer using USB memory stick
- Function Key: User-defined functions (F1~F4). Clock In/Clock Out/Absence/Return
- Multifactor Authentication: Fingerprint, RF card, Password
- Multi Language support with Audio-visual indications
- Built-in battery & PoE (Optional). It uses battery in case of electric disconnection.
- Centralized Biometric Access control on IP technology
