DTH134- Signature Display 13
With a 13.3" Full HD resolution LCD screen, touch functionality and state-of-the-art encryption, the USB-powered Wacom Signature Display 13 Pen & Touch Display sets a new standard in eDocument solutions.DTH134 Overview
The DTH134’s spacious, vivid, and touch-enabled 13.3″ Full-HD LCD enables an optimal user experience for digital document signing, form filling, and document annotation in any business application.
USB charging ensures a clutter-free working environment. Security is ensured with state-of-the-art encryption and a Kensington Nanosaver slot that helps prevent theft.
Exceptional Performance
As with all Wacom products, the Signature Display 13 is extremely durable. Backed by our 3-year standard warranty and 5- year extended warranty*, you can be confident that it will look and perform like new for years to come. And, with a new, thinner device design, and driver-free** installation, workspace integration is easier than ever.
Note: The Wacom Pen Driver is required in order to utilize most Wacom Ink SDKs.
The digital pen is cordless and battery-free, making it light, strong, and low maintenance. With enhanced pressure sensitivity, a higher report rate, and reduced parallax versus the previous model, it has never performed better.
General Specifications
Dimensions (W x H x D) 13.2 x 8.7 x 0.5 inches (336 x 222 x 12 mm)
Weight (including stand) 1.9 lbs / 0.9 kg
Power supply USB Power Delivery or AC Adaptor
Power consumption Max: 15 W(AC Adaptor) / 14.6 W (PC USB PD Port );
Sleep: 1.5W; Off:0.3W
Communication interface USB Type-C
Programmable buttons NA
Supported operating systems Windows® 10 or later; macOS 11 or later
Android OS version 8.0 and above
Chrome™ OS the latest version
Tablet & Pen
Technology Electromagenetic Resonance (EMR)
Screen dimensions 13.3” diagonal (294 x 165 mm)
Report rate 240 reports/second
Pressure levels 4096
Encryption AES 256 / RSA 2048 (via driver)
Reading height 0.3 inches / 8 mm (center)
LCD Display
LCD Panel Type IPS
Touch input Yes
Cover glass surface Anti-glare and anti-fingerprint glass
Aspect ratio 16:9
Native resolution 1920 x 1080 pixels
Video input USB Type-C or HDMI
Viewing angles (horizontal/vertical) 170°(85/85) / 170°(85/85) (typical)
Luminance (brightness) 320 cd/m2
(typical)
Colours 16.7M colors
Contrast ratio 2000:1 (typical)
Response time 19 ms (typical)
Miscellaneous
Pen storage Fabric holder
Security lock slot Kensington Nanosaver
Mounting system None
Signature software compatability Compatible with signature / eSign software and
Wacom sign pro PDF, C++, .NET and Java SDK/API
available for developers
Drivers Wacom Pen Driver required to access full
functionality
Warranty 3-year standard warranty; 5-year extended
warranty (sold separately)
Package content DTH134, Wacom One Standard Pen White-Gray,
replacement nibs and nib removal tool,
1 x USB-C Cable, pen tether
Simplified Integration
Single cable and driver-free installation make workspace integration quick and easy.
VDI Compatibility
Certified for use with Citrix and VMWare virtualized environments – for both pen and touch input.
Enhanced Productivity
Touch functionality can be toggled on and off quickly and easily with a physical switch.
Sustainability
Reduced ecological footprint by reducing packaging, eliminating petroleum-derived plastic and switching to organic, water-based ink.
Secure Transactions
Transaction security with state-of-the-art AES/RSA encryption.
Reduce Clutter
Single cable connection and additional USB-C input built-in. Ideal for saving space when connecting a fingerprint scanner, NFC reader, or other accessories.
The spacious, vivid, and touch-enabled 13.3” Full-HD LCD enables an optimal user experience for digital document signing, form filling, and document annotation in any business application. USB charging ensures a clutter-free working environment. Security is ensured with state-of-the-art encryption and a Kensington Nanosaver slot that helps prevent theft.
As with all Wacom products, the Wacom Signature Display 13 (DTH134) is extremely durable. Backed by our 3-year standard warranty and 5-year extended warranty*, you can be confident that it will look and perform like new for years to come. And, with a new, thinner device design, and driver-free** installation, workspace integration is easier than ever.
Download Brochure: WACOM DTH134 Datasheet
