NScan-FMH USB Fingerprint Scanner – FBI PIV & FAP20 Certified
The NScan-FMH is an FBI PIV and FAP20-certified optical USB fingerprint scanner built by UBio (Union Biometrics) for high-security identity verification, banking KYC, and enterprise access control.
- FBI PIV & FAP20 Certified
- Live Finger Detection (LFD)
- IP65 Dust & Waterproof Rating
- 500 DPI Optical Sensor, 256 Grayscale
- Plug-and-Play USB 2.0
Tags: Fingerprint Sensors
The NScan-FMH uses a 500 DPI optical sensor with 256-level grayscale imaging and captures at 10 frames per second, giving fast, accurate reads even in high-throughput environments such as bank counters or government service desks. It measures 75 x 39.4 x 17.2 mm and connects via USB 2.0 High Speed, requiring no external power supply. The unit is rated for operation between -20°C and +60°C at 10–90% humidity, and its IP65 housing protects against dust ingress and water splashes.
On the security side, the NScan-FMH carries KC, CE, FCC, and RoHS compliance alongside FBI PIV and FAP20 certification — the benchmark used by identity and access programs that require validated capture quality. It supports VIRDI, ISO 19794-2, and ANSI 378 fingerprint template formats, plus ISO 19794-4 WSQ, RAW, and BMP image formats, making it compatible with a wide range of third-party identity and access management platforms.
A full SDK is included, giving developers an API, an enrollment and authentication wizard, and sample code in C++, C#, and Java for Windows, Linux, and Android. This allows eTOP’s UAE customers to integrate the NScan-FMH into existing software rather than being locked into a single vendor’s platform.
Specification | Details |
| Model | NScan-FMH |
| Fingerprint Type | Optical |
| Resolution | 500 dpi |
| Gray Scale | 256 Gray |
| Platen Size (W × L) | 16.6 × 21.6 mm |
| Sensing Area (W × L) | 15.24 × 20.32 mm |
| Auto Sensing | Yes |
| Speed | 10 Frames Per Second (FPS) |
| Interface | USB 2.0 (High Speed) |
| Operating Temperature | -20°C to +60°C |
| Operating Humidity | 10%–90% RH (Non-Condensing) |
| Dimensions (W × H × D) | 75 × 39.4 × 17.2 mm |
| Certifications | KC, CE, FCC, RoHS, FBI PIV+FAP20 |
| Image Format | ISO 19794-4, WSQ, RAW, BMP |
| Template Type | VIRDI, ISO 19794-2, ANSI 378 |
| LFD (Live Finger Detection) | Supported |
| Operating System | Windows, Android |
| Card Type | Not Supported |
| Operating Software (Server Solution) | Not Available |
GET A FREE QUOTE
Key Features of NScan-FMH USB Fingerprint Scanner
- FBI PIV & FAP20 Certified – meets the strictest US federal standard for single-finger optical capture, accepted for KYC, AML, and government-grade identity programs in the UAE.
- Live Finger Detection (LFD) – rejects fake fingerprints made from silicone, rubber, film, paper, or gelatin, preventing spoofing attacks.
- IP65 Dust & Waterproof Rating – reliable in reception desks, outdoor kiosks, warehouses, and high-traffic UAE environments.
- 500 DPI Optical Sensor, 256 Grayscale – matching engine ranked 1st in the FVC (Fingerprint Verification Competition) for high accuracy at speed.
- Plug-and-Play USB 2.0 – no external power needed, works instantly with Windows and Android.
Where the NScan-FMH Is Used
- Banking & Financial Services: KYC onboarding, exchange house counters, and AML-compliant customer verification.
- Government & Data Security: access authentication for restricted IT systems and sensitive records.
- Healthcare: patient identification and staff access in hospitals and clinics.
- Personal Identification Programs: visa processing, visitor registration, and ID verification desks.
Why Buy Through eTOP
eTOP Trading LLC supplies genuine UBio hardware in bulk across the UAE and GCC, with SDK integration guidance, after-sales support, and delivery to Dubai, Abu Dhabi across the Middle East.
What is the NScan-FMH used for?
The NScan-FMH is a USB optical fingerprint scanner used for identity verification, KYC/AML compliance, access control, and biometric enrollment in banking, government, and enterprise systems across the UAE.
Is the NScan-FMH FBI certified?
Yes. The NScan-FMH holds FBI PIV and FAP20 certification, meeting US federal standards for single-finger optical fingerprint capture accuracy and image quality.
Does the NScan-FMH detect fake fingerprints?
Yes. It includes Live Finger Detection (LFD) technology that identifies and rejects spoofed fingerprints made from silicone, rubber, film, paper, or gelatin.
Is the NScan-FMH waterproof?
Yes, the NScan-FMH carries an IP65 rating, making it resistant to dust and water splashes, suitable for reception counters and semi-outdoor kiosks.
Which operating systems support the NScan-FMH?
The NScan-FMH supports Windows and Android operating systems and connects via a standard USB 2.0 (High Speed) plug-and-play interface.
What fingerprint template formats does it support?
It supports VIRDI proprietary templates, ISO 19794-2, and ANSI 378 international standard formats, along with ISO 19794-4 WSQ, RAW, and BMP image formats.
Does eTOP supply the NScan-FMH in bulk for UAE businesses?
Yes, eTOP Trading LLC supplies the NScan-FMH in bulk quantities to banks, government entities, and enterprises across the UAE and GCC, with SDK integration support.
Does the NScan-FMH come with an SDK for software integration?
Yes. UBio provides an SDK with C++, C#, and Java sample code, supporting Windows, Linux, and Android for integration with third-party identity management or access control software.
