BioMini Combo
BioMini Combo supports contact and contactless smartcards with
optional SAM slot. Combined with fingerprint sensor, the scanner
provides capability for two factor authentication for versatile security
solution applications.
Availability : Ex-Stock, Prior to sales
- Description
- Additional information
- Applications
- Specifications
Description
Machine-learning based
Live Finger Detection(LFD)
Technology
BioMini Combo provides advanced machine-learning based Live
Finger Detection technology that distinguishes fake fingerprints
made from various materials including clay, rubber, silicon, glue,
paper, film and more.
Multi Dynamic
Range (MDR) Technology
BioMini Combo can acquire fingerprint regardless of external
light or fingerprint conditions, applying Suprema’s proprietary
MDR technology, an improvement on existing HDR technology.
It can get normal fingerprints even under 100,000 LUX direct light,
which is equivalent to direct sunlight.
FBI PIV and Mobile ID FAP20
Certified Image Quality
The Scanner features Large Platen that spans
0.71” x 1.0” (18mm x 25.4mm) wide, which is well
above the FAP20 Standard that spans 0.6” x 0.8”.
Additional information
| Industries | Energy & Utilities, Healthcare, Manufacturing, Public Sector, Retail |
|---|
· Smartcard Application
· Time and Attendance System
· Public Application
· Health and Medical
· Banking/Finance
· POS/mPOS
· ATM/Kiosk
· Enterprise
| Main | Sensor Type | Optical |
|---|---|---|
| Resolution / Gray Scale | 500 ppi / 256 levels | |
| Platen Size | 18.0 x 25.4 mm | |
| Sensing Area | 16.2 x 24.3 mm | |
| Image Size | 320 x 480 pixels | |
| Image Certificate | FBI PIV and FBI Mobile ID FAP 20 | |
| Template Format | Suprema, ISO 19794-2, ANSI 378 | |
| Image Format | RAW, BMP, WSQ, ISO 19794-4 | |
| Live Fingerprint Detection | Supported | |
| IP Rating | IP65(Sensor Surface) | |
| Contact Card Support | Contact Smart Card Reader | ISO 7816 Class A/B/C (5V, 3.0V, 1.8V) T=0, T=1 EMV2000 contact smart card with SAM Slot(optional, max 2x SAM) |
| Contactless Card Support | Contactless Smart Card Reader | ISO/IEC 14443 A&B, Mifare, Felica NFC Forum tag types (Jewel, Mifare Ultralight, Felica, Felica lite, Mifare, DesFire) EMV2000 Contactless Smart Card Frequency 13.56MHz +/- 7KHz Distance transaction: Up to 10cm Baud: 106/212/424/848 kbit/s |
| Interface | USB | 2.0 High Speed CCID, PC/SC driver |
| Hardware | Operating Temperature | -10 ~ 50°C |
| Operation Humidity | 0 ~ 90% RH | |
| Certification | CE, FCC, KC, RoHS, WHQL | |
| Dimensions(W x L x H) | 95.7 x 114.8 x 52.6 mm | |
| Weight | 280g | |
| Compatibility | Operating System | Windows XP, Vista, 7, 8, 8.1, 10 32/64bit Ubuntu, Debian, Fedora, OpenSUSE, CentOS 32/64bit |
